processor system

cpu

6305e

i3-1115g4

i3-1115g4e

i3-1125g4

i5-1135g7

i7-1165g7

frequency

1.80ghz

up to 4.10ghz

up to 3.9ghz

up to 3.70 ghz

up to 4.20ghz

up to 4.7ghz

core/thread

2/2

2/4

2/4

4/8

4/8

4/8

llc

4 mb

6 mb

6 mb

8 mb

8 mb

12 mb

cpu tdp

15w

28w

28w

28w

28w

28w

bios

ami uefi bios

memory

technology

ddr4-3200 mhz

ecc support

n/a

max. capacity

64gb

channel / socket

2 * so-dimm slot

graphics

controller

intel® uhd graphics

max. frequency

1.25ghz

1.25ghz

1.25ghz

1.25ghz

1.3ghz

up to 96 eus, 1.3ghz

display

edp

4096×2304@60hz

dp

7680×4320@60hz

hdmi

4096×2304@60hz

mipi-dsi

4096×2304@60hz

3d/hw acceleration

hardware encode/transcode of hd content (including hevc)

directx 12 support

opengl 4.5, 4.4/4.3 and es 2.0 support

opencl 2.1, 2.0/1.2 support

multiple display

four displays with each display combinations

serial bus

smbus

yes

expansion

pci express x1

up to 5 pcie×1(gen3)，

pci express x4

1 pcie×4 (gen4)

audio interface

1 intel hd audio interface

ethernet

controller

intel i219，up to 1 port

speed

10/100/1000 mbps

i/o

usb3.0

4 ports

usb2.0

10 ports

sata3.0

2 port (6gbps)

gpio

10 gpios

watchdog

bios support

com port

6 ports (4 ports 2-wire / 2 ports 8-wire)

smart fan

system fan(option support)

spi bus

yes

power

type

dc in

supply voltage

vin: 9~12v, rtc battery: 2.0v ~ 3.3v

environment

operating temperature

standard: 0 ~ 60 °c

storage temperature

standard: -20 ~ 75 °c

humidity

operating: 40 °c @ 95% relative humidity, non-condensing

storage: 60 °c @ 95%relative humidity, non-condensing

vibration resistance

3.5 grms

mechanical

dimensions

82 mm×95 mm
