features
●pcie 2.0 compliant. rs-232/485 mode configurable by switch.
●supports 232fd(full duplex) and 485hd(half duplex).
●up to 25 mbps serial data rate. 16c550 compatible. 256-byte fifos
●industrial temperature(-40℃ to 85℃ ) operation.
●flexible design with db-9 connectors and cable.
●esd up to 15kv(electrostatic discharge) protection circuit to prevent system damage.
●30µ" golden finger, 3 years warranty.
●industrial design, manufactured in yanzhi hangzhou
switch and definition of connectors
specifications
| form-factor | mpcie |
| input i/f | pci express 2.0 x 1 |
| output i/f | rs-232/485 |
| output connector | db-9 x 2 |
| tdp | 0.33w (3.3v x 100ma) |
| dimension (w*l*h) | 30 x 50.9 x 8.25 mm |
| temperature |
operation: w/t: -40°c ~ 85°c storage: -55°c ~ 95°c |
| environment | vibration: 5g @7~2000hz, shock: 50g @ 0.5ms |
| notes |
please download driver from suqin@rt-ics.com. windows: xp(32 bit), 7(32/64 bit), 8/8.1(32/64 bit), 10,wes7, ce7.0 linux: kernel 2.6.x and above. |
