●models
this manual is applied to following models:| model | cpu | com | usb |
| yzpc-3910 | i7 | 6 | 8 |
| lan | vga | mini pci-e | lvds |
| 2 | 1 | 2 | dual 24-bit |
●attentions
●notes under a table or figure indicate the difference of models, or alternative definition of specific pin of the header (jumper/connector).●how to identify the first pin of a header or jumper
■usually, there is a thick line or a triangle near the header’s or jumper’s pin 1.
■square pad, which you can find on the back of the motherboard, is usually used for pin 1.
●specification
| model | yzpc-3910 |
| cpu | intel® celeron® processor 3855u,dual core,2m cache, 1.60 ghz,tdp 15w |
| intel® celeron® processor 3955u,dual core,2m cache, 2.00 ghz,tdp 15w | |
| intel® core™ i3-6100u processor,dual core,3m cache,2.30 ghz,tdp 15w | |
| intel® core™ i5-6300u processor,dual core,3m cache,3.00 ghz,tdp 15w | |
| intel® core™ i7-6660u processor,dual core,4m cache,3.40 ghz,tdp 15w | |
| display | 1 * dual channel 24-bit lvds |
| memory | support ddr4-2133, lpddr3-1866, ddr3l-1600,sodimm,up to 32gb |
| storage | 1 * serial ata 2.0 port 1 * msata |
| ethernet | 2 * rtl8111e/8105e for 1000mbps |
| audio |
realtek alc269q hda codec,support mic/line-out ports 1 * amplifier, 2.3w (per channel) into an 4ωloads |
| com | 6* rs232 |
| other ports |
8 * usb 8 * gpio 1 * jvga 1 * mini pci-e for wifi/3g 2 * sim card 1 * 12vdc_in power input connector |
| temperature |
storage: -20~85 oc operating: 0~60 oc |
| bios | ami uefi bios |
| factor | 156mm * 101.96mm |
●jumpers/headers and connectors
| jumpers / headers and connectors | |||
| jme | 1 | 2 | dc_pwr |
| cpu_fan | 3 | 4 | sys_fan |
| lvds | 5 | 6 | ivcn_lvds |
| sata_pwr | 7 | 8 | sata |
| jlv_lvds | 9 | 10 | j2 |
| jcmos | 11 | 12 | ivcn_edp |
| edp | 13 | 14 | gpio |
| bat | 15 | 16 | jvga |
| usb3 | 17 | 18 | usb1 |
| f_audio | 19 | 20 | f_spk |
| lan1 | 21 | 22 | lan2 |
| usb2 | 23 | 24 | usb4 |
| rs232 | 25 | 26 | rs232 |
| jc5 | 27 | 28 | jc6 |
| jc4 | 29 | 30 | jc2 |
| jc1 | 31 | 32 | jc3 |
| front panel | 33 | 34 | sodimm |
| watch dog | 35 | 36 | wifi/3g |
| simcard1 | 37 | 38 | simcard2 |
| msata | 39 | ||
●definition of jumpers/headers and connectors
jme
jme
| definition | pin | pin | definition |
| v3.3s_hda | 1 | 2 | hda_spkr |
dc_pwr1
dc_pwr1
| definition | pin | pin | definition |
| gnd1 | 1 | 2 | gnd2 |
| 12v1 | 3 | 4 | 12v2 |
cpu_fan1
cpu_fan1
| definition | pin | pin | definition |
| v5s_fan | 1 | 2 | gnd |
| cpu_fantach | 3 |
sys_fan1
sys_fan1
| definition | pin | pin | definition |
| gnd | 1 | 2 | vcc |
| det | 3 |
lvds1
lvds1
| definition | pin | pin | definition |
| lcdvdd | 1 | 2 | lcdvdd |
| lvds_det | 3 | 4 | gnd |
| lcdvdd | 5 | 6 | lcdvdd |
| a0m | 7 | 8 | a4m |
| a0p | 9 | 10 | a4p |
| gnd | 11 | 12 | gnd |
| a1m | 13 | 14 | a5m |
| a1p | 15 | 16 | a5p |
| gnd | 17 | 18 | gnd |
| a2m | 19 | 20 | a6m |
| a2p | 21 | 22 | a6p |
| gnd | 23 | 24 | gnd |
| clk1m | 25 | 26 | clk2m |
| clk1p | 27 | 28 | clk2p |
| gnd | 29 | 30 | gnd |
| spc1 | 31 | 32 | spd1 |
| gnd | 33 | 34 | gnd |
| a3m | 35 | 36 | a7m |
| a3p | 37 | 38 | a7p |
| v3.3s | 39 | 40 | gnd |
ivcn_lvds1
ivcn_lvds1
| definition | pin | pin | definition |
| v12s | 1 | 2 | gnd |
| enabkl | 3 | 4 | bklt_pwm |
| v5s | 5 |
sata_pwr1
sata_pwr1
| definition | pin | pin | definition |
| v12s | 1 | 2 | gnd |
| gnd | 3 | 4 | v5s |
sata1
sata1
| definition | pin | pin | definition |
| gnd | 1 | 2 | sata0txp |
| sata0txn | 3 | 4 | gnd |
| sata0rxn | 5 | 6 | sata0rxp |
| gnd | 7 | 8 | gnd |
| gnd | 9 |
jlv_lvds1
jlv_lvds1
| setting | function |
| 1-2(default) | 3.3v |
| 2-3 | 5v |
j2
j2
| definition | pin | pin | definition |
| blup | 1 | 2 | gnd |
| bldn | 3 |
jcmos
jcmos
| setting | function |
| 1-2(default) | normal |
| 2-3 | clear cmos |
ivcn_edp1
ivcn_edp1
| definition | pin | pin | definition |
| v12s | 1 | 2 | gnd |
| edp_bklt_en | 3 | 4 | edpbklt_ctl |
| v5s | 5 |
edp1
edp1
| definition | pin | pin | definition |
| v3.3dx_edp | 1 | 2 | v3.3dx_edp |
| gnd | 3 | 4 | edp_det |
| edp_tx0_c_dp | 5 | 6 | edp_tx2_c_dp |
| edp_tx0_c_dn | 7 | 8 | edp_tx2_c_dn |
| gnd | 9 | 10 | gnd |
| edp_tx1_c_dp | 11 | 12 | edp_tx3_c_dp |
| edp_tx1_c_dn | 13 | 14 | edp_tx3_c_dn |
| gnd | 15 | 16 | gnd |
| edp_auxp_c | 17 | 18 | hpd1 |
| edp_auxn_c | 19 | 20 | nc |
gpio1
gpio1
| definition | pin | pin | definition |
| v5s | 1 | 2 | v12s |
| gpp_d9 | 3 | 4 | gpp_d13 |
| gpp_d10 | 5 | 6 | gpp_d14 |
| gpp_d11 | 7 | 8 | gpp_d15 |
| gpp_d12 | 9 | 10 | gpp_d16 |
| gnd | 11 | 12 | gnd |
bat1
bat1
| definition | pin | pin | definition |
| vccrtc | 1 | 2 | gnd |
| gnd | 3 | 4 | gnd |
jvga1
jvga1
| definition | pin | pin | definition |
| rout | 1 | 2 | gnd |
| gvcc | 3 | 4 | gout |
| gnd | 5 | 6 | vga_sda |
| bout | 7 | 8 | gnd |
| vga_hsync | 9 | 10 | gvcc |
| gvcc | 11 | 12 | vga_vsync |
| gnd | 13 | 14 | gnd |
| vga_scl | 15 | 16 | nc |
usb3
usb3
| definition | pin | pin | definition |
| rusb_pwr | 1 | 2 | usb3_rx3_dn |
| usb3_rx3_dp | 3 | 4 | gnd |
| usb3_tx3_dn_c | 5 | 6 | usb3_tx3_dp_c |
| gnd | 7 | 8 | usb_dn3 |
| usb_dp3 | 9 | 10 | nc |
| usb_dp4 | 11 | 12 | usb_dn4 |
| gnd | 13 | 14 | usb3_tx4_dp |
| usb3_tx4_dn | 15 | 16 | gnd |
| usb3_rx4_dp | 17 | 18 | usb3_rx4_dn |
| rusb_pwr | 19 |
usb1
usb1
| definition | pin | pin | definition |
| rusb_pwr | 1 | 2 | usb3_rx1_dn |
| usb3_rx1_dp | 3 | 4 | gnd |
| usb3_tx1_dn_c | 5 | 6 | usb3_tx1_dp_c |
| gnd | 7 | 8 | usb_dn1 |
| usb_dp1 | 9 | 10 | nc |
| usb_dp2 | 11 | 12 | usb_dn2 |
| gnd | 13 | 14 | usb3_tx2_dp_c |
| usb3_tx2_dn_c | 15 | 16 | gnd |
| usb3_rx2_dp | 17 | 18 | usb3_rx2_dn |
| rusb_pwr | 19 |
f_audio1
f_audio1
| definition | pin | pin | definition |
| mic1-l | 1 | 2 | gnd |
| mic1-r | 3 | 4 | v3.3s |
| hp-r | 5 | 6 | mic1-jd |
| gnd | 7 | ||
| hp-l | 9 | 10 | hp-jd |
f_spk1
f_spk1
| definition | pin | pin | definition |
| intspl | 1 | 2 | intspl |
| intspr | 3 | 4 | intspr |
usb2
usb2
| definition | pin | pin | definition |
| usbpwr | 1 | 2 | usbpwr |
| -data5 | 3 | 4 | -data6 |
| data5 | 5 | 6 | data6 |
| gnd | 7 | 8 | gnd |
| nc | 9 | 10 | gnd |
usb4
usb4
| definition | pin | pin | definition |
| usbpwr | 1 | 2 | usbpwr |
| -data7 | 3 | 4 | -data8 |
| data7 | 5 | 6 | data8 |
| gnd | 7 | 8 | gnd |
| nc | 9 | 10 | gnd |
lvds_0 cn2
lvds_0 cn2
| definition | pin | pin | definition |
| s_dcd4 | 1 | 2 | rxd4* |
| txd4* | 3 | 4 | dtr4 |
| gnd | 5 | 6 | dsr4* |
| rts4 | 7 | 8 | cts4 |
| ri4 | 9 | 10 | nc |
| s_dcd5 | 11 | 12 | rxd5* |
| txd5* | 13 | 14 | dtr5 |
| gnd | 15 | 16 | dsr5* |
| rts5 | 17 | 18 | cts5 |
| ri5 | 19 | 20 | nc |
| s_dcd6 | 21 | 22 | rxd6* |
| txd6* | 23 | 24 | dtr6 |
| gnd | 25 | 26 | dsr6* |
| rts6 | 27 | 28 | cts6 |
| ri6 | 29 | 30 | nc |
| gnd | 31 | 32 | gnd |
lvds_0 cn1
lvds_0 cn1
| definition | pin | pin | definition |
| s_dcd1 | 1 | 2 | rxd1* |
| txd1* | 3 | 4 | dtr1 |
| gnd | 5 | 6 | dsr1* |
| rts1 | 7 | 8 | cts1 |
| ri1 | 9 | 10 | nc |
| s_dcd2 | 11 | 12 | rxd2* |
| txd2* | 13 | 14 | dtr2 |
| gnd | 15 | 16 | dsr2* |
| rts2 | 17 | 18 | cts2 |
| ri2 | 19 | 20 | nc |
| s_dcd3 | 21 | 22 | rxd3* |
| txd3* | 23 | 24 | dtr3 |
| gnd | 25 | 26 | dsr3* |
| rts3 | 27 | 28 | cts3 |
| ri3 | 29 | 30 | nc |
| gnd | 31 | 32 | gnd |
jc5
jc5
| definition | pin | pin | definition |
| v5s_com | 1 | 2 | s_dcd5 |
| dcd5 | 3 |
jc6
jc6
| definition | pin | pin | definition |
| v5s_com | 1 | 2 | s_dcd6 |
| dcd6 | 3 |
jc4
jc4
| definition | pin | pin | definition |
| v5s_com | 1 | 2 | s_dcd4 |
| dcd4 | 3 |
jc2
jc2
| definition | pin | pin | definition |
| v5s_com | 1 | 2 | s_dcd2 |
| dcd2 | 3 |
jc1
jc1
| definition | pin | pin | definition |
| v5s_com | 1 | 2 | s_dcd1 |
| dcd1 | 3 |
jc3
jc3
| definition | pin | pin | definition |
| v5s_com | 1 | 2 | s_dcd3 |
| dcd3 | 3 |
front panel
f_panel1
| definition | pin | pin | definition |
| pwrbtn# | 1 | 2 | v3.3s |
| gnd | 3 | 4 | hddled# |
| reset_sw | 5 | 6 | v3.3s |
| gnd | 7 | 8 | gnd |
| 10 | gnd |
watch dog
j4
| definition | pin | pin | definition |
| watch dog | 1 | 2 | gnd |
